Canon TS-E 17mm f/4L Lens

TS-E 17mm f/4L Lens

• Focal Length & Maximum Aperture: 17mm 1:4
• Tilting and shifting range of +/- 90°
• Aspherical element for glare-free image quality
• Circular aperture for beautiful out-of-focus areas
• Diagonal Angle of View: 104° (without tilt or shift

In the Box

• TS-E 17mm f/4L Lens
• Lens Case LP1219
• Unit Option Cap
• Instruction Book
• One Year Limited Warranty Card
• Wrist Strap WS-DC7

The widest tilt-shift lens in Canon's lineup, the new TS-E 17mm f/4L lens expands shooting possibilities exponentially on EOS Digital cameras. Designed with UD glass to minimize and compensate for chromatic aberrations, with a specially coated aspherical element for the highest possible glare-free image quality, this tilt-shift lens offers a diagonal angle of view of 104° on a full-frame SLR camera.

New TS rotation lets users freely combine tilting and shifting within the range of +/- 90° in the direction of movement. The lens also has an improved tilt & shift knob with an enhanced range of movement of up to +/- 6.5° and 12mm respectively, with a revolving function for better operability. It uses a circular aperture for beautiful out-of-focus areas and has an SWC lens coating to control ghosting and flare to a far greater degree than with earlier coating technologies.

Specifications

Focal Length & Maximum Aperture : 17mm 1:4
Minimum Aperture : f/22
Lens Construction : 18 elements in 12 groups
Diagonal Angle of View : 104° (without tilt or shift)
Image Circle Diameter : 67.2mm
Focus Adjustment : Manual focus, rear focusing system with focusing cam (with floating system)
Closest Focusing Distance : 0.82 ft./0.25m (maximum close-up magnification: 0.14x)
Aperture Control : EMD with 8 blade iris diaphragm, circular aperture
Max. Diameter x Length, Weight : 3.5 x 4.2 in./88.9 x 106.7mm (maximum lens length), 28.9 oz./820g
Lens Cap, Lens Hood and Pouch : Lens cap and pouch provided. (No lens hood available.)
