Liberty AV Solutions TeamUp+ Series Multi Format Docking Station with USB Capture
TeamUp+ Series Multi‑Format Docking Station / USB Capture
Professional multi‑format docking and USB‑capture hub featuring HDMI, HDBaseT, and SDI inputs, built‑inUSB capture capability, dual‑display output, and a single‑cable USB‑C host connection for modern BYOMand collaboration workflows.
Key Features
- Supports HDMI, HDBaseT, and SDI input formats
- Built‑in USB capture card converts all input types to USB, supporting resolutions up to 4K60 for seamless collaboration, streaming, and content‑sharing applications
- Dual HDMI outputs with mirrored HDBaseT 3.0 output, supporting DisplayLink for extended or different content on local and remote displays
- Analog audio embedding & de‑embedding for flexible audio routing
- 4‑port USB 3.0 client hub for peripherals such as cameras, speakerphones, and touch displays
- EDID Management for optimal signal negotiation across connected devices
- USB‑C host interface with Ethernet pass‑through and up to 100W charging for single‑cable connectivity to laptops and host computers
- IP & RS‑232 connections for control system integration and remote management
Product Overview
The TeamUp+ Series Multi‑Format Docking Station / USB Capture solution is engineered for professional collaboration spaces that require flexible video ingest, connectivity, and high‑quality USB capture. With support for HDMI, HDBaseT, and SDI video sources, the docking station enables seamless integration of a wide variety of devices—including room PCs, cameras, media players, broadcast equipment, and remote content sources.
A powerful built‑in capture engine converts any connected source into a USB video feed at up to 4K60 resolution, ensuring compatibility with conferencing platforms, streaming software, and content‑sharing workflows. The dual‑display architecture, paired with mirrored HDBaseT 3.0 output, allows users to present different content on local and remote displays using DisplayLink technology—ideal for hybrid meeting spaces, classrooms, and multi‑screen collaboration environments.
The integrated 4‑port USB 3.0 hub allows cameras, speakerphones, touch displays, and other peripherals to connect directly to the docking station, while the USB‑C host port provides a true single‑cable solution: video, USB data, Ethernet networking, and up to 100W power delivery all travel through one cable. This reduces clutter and simplifies the user experience, making the docking station ideal for BYOD/BYOM rooms where guests need quick, familiar connectivity.
With robust EDID management, analog audio embedding/de‑embedding, and both IP and RS‑232 control options, the TeamUp+ Multi‑Format Docking Station is built for deployment in enterprise, education, government, and broadcast‑grade environments. It offers outstanding flexibility, professional‑grade signal handling, and the centralized functionality necessary for modern collaboration ecosystems.
Original: $1,771.51
-65%$1,771.51
$620.03Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
TeamUp+ Series Multi‑Format Docking Station / USB Capture
Professional multi‑format docking and USB‑capture hub featuring HDMI, HDBaseT, and SDI inputs, built‑inUSB capture capability, dual‑display output, and a single‑cable USB‑C host connection for modern BYOMand collaboration workflows.
Key Features
- Supports HDMI, HDBaseT, and SDI input formats
- Built‑in USB capture card converts all input types to USB, supporting resolutions up to 4K60 for seamless collaboration, streaming, and content‑sharing applications
- Dual HDMI outputs with mirrored HDBaseT 3.0 output, supporting DisplayLink for extended or different content on local and remote displays
- Analog audio embedding & de‑embedding for flexible audio routing
- 4‑port USB 3.0 client hub for peripherals such as cameras, speakerphones, and touch displays
- EDID Management for optimal signal negotiation across connected devices
- USB‑C host interface with Ethernet pass‑through and up to 100W charging for single‑cable connectivity to laptops and host computers
- IP & RS‑232 connections for control system integration and remote management
Product Overview
The TeamUp+ Series Multi‑Format Docking Station / USB Capture solution is engineered for professional collaboration spaces that require flexible video ingest, connectivity, and high‑quality USB capture. With support for HDMI, HDBaseT, and SDI video sources, the docking station enables seamless integration of a wide variety of devices—including room PCs, cameras, media players, broadcast equipment, and remote content sources.
A powerful built‑in capture engine converts any connected source into a USB video feed at up to 4K60 resolution, ensuring compatibility with conferencing platforms, streaming software, and content‑sharing workflows. The dual‑display architecture, paired with mirrored HDBaseT 3.0 output, allows users to present different content on local and remote displays using DisplayLink technology—ideal for hybrid meeting spaces, classrooms, and multi‑screen collaboration environments.
The integrated 4‑port USB 3.0 hub allows cameras, speakerphones, touch displays, and other peripherals to connect directly to the docking station, while the USB‑C host port provides a true single‑cable solution: video, USB data, Ethernet networking, and up to 100W power delivery all travel through one cable. This reduces clutter and simplifies the user experience, making the docking station ideal for BYOD/BYOM rooms where guests need quick, familiar connectivity.
With robust EDID management, analog audio embedding/de‑embedding, and both IP and RS‑232 control options, the TeamUp+ Multi‑Format Docking Station is built for deployment in enterprise, education, government, and broadcast‑grade environments. It offers outstanding flexibility, professional‑grade signal handling, and the centralized functionality necessary for modern collaboration ecosystems.
