Vaddio ZoomSHOT 4K with OneLINK HDMI System

ZoomSHOT® 4K Camera with OneLINK HDMI System

The ZoomSHOT® 4K with OneLINK HDMI System is a low‑cost, high‑performance point‑of‑view camera solution delivering stunning UHD 4K image quality. Designed for small, medium, and large rooms, it supports a wide range of applications including houses of worship, pro AV system integration, live events, IMAG systems, UCC applications, videoconferencing, distance learning classrooms, and lecture capture.

Featuring a 1/2.5" Sony Exmor™ CMOS image sensor, the ZoomSHOT 4K captures sharp 2160p/30 video with a 30x optical zoom and a wide 70.2° horizontal field of view. Manual pan and tilt with an EZ Set tensioning system allow precise framing, while a presenter‑friendly IR remote makes operation simple and intuitive.

The included OneLINK HDMI extension system enables HDMI video, control, and power to be extended up to 150 ft (45.7 m) over a single cable for clean, professional installations. The camera can also be used as a standalone device without an extension system if desired.

Key Features

• UHD 4K video output up to 2160p/30
• 30x powered optical zoom with 70.2° horizontal field of view
• HDMI video output with OneLINK HDMI extension support
• Manual pan and tilt with EZ Set tensioning system
• RS‑232 control for third‑party system integration
• Local 12V camera power or remote power via OneLINK system
• Compatible with Kensington security lock

What’s Included

• ZoomSHOT 4K camera (Black or White)
• Thin‑profile wall mount with mounting hardware (Black or White)
• Vaddio IR Shot Commander remote (includes 2 × AAA batteries)
• OneLINK HDBaseT EZIM (Easy Interface Module)
• Cables to connect ZoomSHOT 4K camera to EZIM
• OneLINK HDMI HDBaseT extension
• 48V power supply for OneLINK Bridge with AC cord set(s)

Dimensions & Measurements

• Camera Dimensions: 5.5" W × 7" H × 5.8" D (14 × 17.78 × 14.73 cm)
• QMini Dimensions: 4.46" W × 1.24" H × 3.58" D (11.3 × 3.15 × 9.1 cm)
• Product Weight: Camera 3.5 lbs (1.59 kg); QMini 1.12 lbs (0.51 kg)
• Shipping Weight: 1 lb (0.5 kg)
• Maximum Distance Supported: 150 ft (45.7 m)

Performance & Technical Specifications

• Camera Type: Fixed
• Image Sensor: 1/2.8" Exmor CMOS
• Total Pixels: 2.14 Megapixels
• Maximum Resolution: 2160p @ 30 fps
• Minimum Illumination: 0.3 Lux
• Zoom: 30x optical
• Field of View: 70.2° (wide)
• Pan Range: Unlimited (manual)
• Tilt Range: +30° / −30°
• Preset Positions: 16

Connectivity & Control

• Output Ports: HDMI 1.4b, RS‑232
• Input Ports: EZ Power Video, RS‑232
• Control Methods: IR Remote, RS‑232
• Signal Type: USB 2.0
• Power Type: EZ Power (Local or OneLINK)
• Quick‑Connect Compatibility: QMini

Environmental & Compliance

• Operating Temperature: 32°–104°F (0°–40°C)
• TAA Compliant: Yes
• Certifications: CE, FCC, TAA
• Warranty: 3 Years
• UPC: 840077509088
